Riverside Plaza Building vs LaSalle-Wacker Building


Comparing the Riverside Plaza Building and the LaSalle-Wacker Building is especially interesting because they share much in common. Both rise in Chicago, IL both were designed by Holabird & Root, and they were completed just one year apart.
This overlap gives us a unique opportunity to understand how Holabird & Root approached different commissions in the same urban context and historical context during a short period.
Height & Size
The LaSalle-Wacker Building is clearly the larger tower of the two, both in terms of height and number of floors. It rises to 512ft (156m) with 41 floors above ground, while the Riverside Plaza Building reaches 302ft (92m) with 26 floors above ground.
Of course, each project may have faced different briefs or regulatory constraints, which we don't really know about and could also explain the outcome.
Architectural Style
Both the Riverside Plaza Building and the LaSalle-Wacker Building were designed in line with the aesthetic conventions of the Art Deco style.
At the time, this style was at the height of its popularity. So Holabird & Root followed what was in many ways expected at the time, producing designs that fit comfortably within contemporary architectural norms rather, than breaking with convention.
Uses
Both the Riverside Plaza Building and the LaSalle-Wacker Building were designed to serve as commercial towers, and that has remained their main use since their completion, serving similar roles in the urban fabric.
The LaSalle-Wacker Building also provides 95 parking spaces.
Structure & Facade
Both the Riverside Plaza Building and the LaSalle-Wacker Building rely on a Frame structural system.
A frame structure uses a grid of columns and beams to carry the building's loads. This frees the walls from structural duties, allowing for flexible floor plans and larger windows.
They also employ the same type of facade, a Masonry facade.
A masonry facade gives the building a heavier, more traditional appearance. It often conceals a frame structure behind it, creating the look of solid walls without carrying the main loads.
Riverside Plaza Building | LaSalle-Wacker Building | |
---|---|---|
Holabird & Root | Architect | Holabird & Root |
1928 | Construction Started | 1929 |
1929 | Year Completed | 1930 |
Art Deco | Architectural Style | Art Deco |
Commercial | Current Use | Commercial |
26 | Floors Above Ground | 41 |
92 m | Height (m) | 156 m |
Frame | Structure Type | Frame |
Steel | Vertical Structure Material | Steel |
Concrete | Horizontal Structure Material | Concrete |
No | Facade Structural? | No |
Frank E. Brown | Structural Engineer | Smith & Brown |
IL | State | IL |
Chicago | City | Chicago |
2 N Riverside Plaza | Address | 221 LaSalle Street |
